    4x Chromoly Panhard Bar Rod End 5/8 x 3/4-16 Heim Joint Bungs .120" Wall XMRL10-12

    317.98 158.99
    50% Off

    Unit Type : Heim Joint

    Material : Chromoly

    Quantity: 4 Pairs

    Bung Size : 1" 1/4 OD. x .120" Wall x 1.01" ID

    Bore Size : 5/8" (.625" )

    Thread Size : 3/4"-16

    Heim Joint Dimensions(please confirm the size specification before purchasing order to avoid buying mistakes!!)

    Rod End (XML12 & XMR12)

    • Material:Heat Treated Chromoly, Hard Chrome Plated, Loader Slot Rod End
    • Thread Size: 3/4"-16
    • Ball Bore: .625"
    • Ball Width: .750"
    • Centerline Length: 2.875"
    • Thread Length: 1.750"
    • Load Capacity: 40,572 lbs

    3/4 Bung (WTF-1204L &WTF1204R)

    • Material: Chromoly
    • Thread Size: 3/4"-16
    • Bung Size: 1" 1/4 OD. x .120" Wall x 1.01" ID.

    Jam Nut (JNL12S & JNR12S)

    • Thread: 3/4"-16
    • Width: 1 1/8" (1.125")
    • Height: 27/64"

    Package Includes

    • 4 x RH 3/4"-16 Jam Nut
    • 4 x LH 3/4"-16 Jam Nut
    • 4 x RH 3/4"-16 Thread, 5/8" Bore
    • 4 x LH 3/4"-16 Thread, 5/8" Bore
    • 4 x RH Tube Adapter
    • 4 x LH Tube Adapter
