Hexautoparts AC Compressor Installation Instruction
Step 1
Remove dead compressor, receiver drier or accumulator,orificetube or expansion valve.
Step 2
Flush the condenser and evaporator using NON-OlL BASED A/C flush. On expansion valve systems.The valve must be removed before the evaporator can be flushed. Flushed condensers from outlet to inlet and evaporators from inlet to outlet.
Step 3
Drain all the oil from the new hexautoparts ac compressor and dispose of according to local, state and federal laws. (NOTE: if your compressor has a drain plug.you will need to open it up and drain what oil is in there too.)
Step 4
Install half oil charge into the compressor and the remainder throughout the system. Turn compressor shaft 8-10 full revolutions to insure front seal and other internal parts arel ubricated.
Step 5
Install new receiver drier or accumulator and new orifice tube or expansion valve.
Step 6
Evacuate the A/C system for a minimum of one hour.
Step 7
After evacuation install half the refrigeran charge and let the system set for l minute. This will allow the refrigerant to pick up oil and spread more evenly throughout the system.
Step 8
Start engine whit A/C controls on MAx AiR with door and windows open.
Step 9
Add the remaining charge of refrigerant as called for by the manufacture.
